    Prostheses for foot,
    leg & hip
    Hip disarticulation prosthesis
Icon Hüftexprothese | © Pohlig GmbH
Hip disarticulation prosthesis

The entire prosthesis is controlled via the pelvis or pelvic shaft.

Physiotherapie | © Pohlig GmbH
Physiotherapy

We train you in the daily use of your hip disarticulation prosthesis

Make an appointment

Make an appointment over the phone or send us a message!

Hüftexartikulation | © Pohlig GmbH

Prosthetic treatment following hip disarticulation

In a hip disarticulation, the entire leg is amputated by a disarticulation (=surgical removal of the entire lower limb by transection through the hip joint). This removes the femoral head from the acetabulum, usually preserving the pelvis and ischium. In a hemipelvectomy, the leg and parts of the pelvis are amputated. Hip disarticulation is necessary in cases such as tumors, severe trauma and infections.

Hip disarticulation poses a major challenge for prosthetic treatment – a leg prosthesis is usually controlled by the user’s lower leg stump or thigh stump. In the case of hip disarticulation, on the other hand, there is no corresponding stump. Control is taken over exclusively by the pelvis. This special situation makes the manufacture of a hip disarticulation prosthesis (HDP) an absolute specialty in leg prosthetics, which requires a high level of expertise.

Gait pattern with hip disarticulation prosthesis

Components of a hip disarticulation prosthesis:

Beckenschaft-System | © Pohlig GmbH
Pelvic socket system

The pelvis is embedded in an HTV silicone contact socket called the “pelvic socket”. It makes up the connection between the prosthesis and the body. The design of the socket has a significant influence on the comfort and operability of the prosthesis.

You can choose between three concepts:

  • two-piece pelvic socket with dorsal locking technology and individual silicone hip pants
  • semi-flexible pelvic socket with individual silicone hip pants
  • classic pelvic harness
Prothesenpassteile | © Pohlig GmbH
Prosthesis fitting parts

Hip joint: Both hip and knee joints are used to regulate the swing and standing phase. Among other things, we use the Ottobock hip joints (e.g. 7E10 Helix hip joint, 7E9), which our users were able to be convinced about, thanks to their function.

Knee joint: For safe, dynamic walking and to fully exploit the function of the hip joint, Ottobock’s electric legs (e.g. C-Leg, Genium, Kenevo) are recommended.

Foot: Various carbon spring foot systems are used, depending on the respective mobility.

Kosmetiken bei einer Hüftexprothese | © Pohlig GmbH
Cosmetics

Cosmetically, there are two options:

  • a classic PUR foam cosmetic that stretches over the knee, is soft and worn with cosmetic socks. This cosmetic is suitable for users who are defensive about the topic of prosthetics and want a good result when sitting.
  • a split variant that keeps the joints free and therefore has little influence on the function of the prosthesis. This cosmetic is popular with users who are actively engaged with the prosthesis.

Hüftexprothese | © Pohlig GmbH
Innovation

Unique socket concept with silicone hip pants

Guiding a hip disarticulation prosthesis requires a great deal of concentration and energy on the part of the user. With the limited control of the pelvis, it must be possible to coordinate the movement of the mechanical ankle joint, knee joint and hip joint fitting parts.

The prosthetic socket plays a central role here. Its fit must be as close as possible to the body and free of pressure points, with little restriction of movement in the lumbar region and an option for direct control. We have risen to this challenge and have been able to develop new materials and working techniques that significantly improve socket comfort. Our innovative socket concept envisages the use of individual silicone hip pants.

Beckenschaft-System | © Pohlig GmbH

Two-part pelvic socket with silicone hip pants

The components

HTV-Silikonhose | © Pohlig GmbH
HTV silicone pants

By closing the silicone pants, the user compresses all soft tissues and thus prevents their uncontrolled movement. This means that the stump in the pants is compressed over a large area. This compression creates a strong, firm (stump) surface that provides the pelvic socket with the necessary support. The stump is therefore put into good condition by the silicone pants in order to absorb the socket and to create the smoothest possible adaptation between stump and prosthesis.

The silicone pants form a clear separating layer to the pelvic harness. The material silicone is used in various shore hardness grades. Thus, the HTV silicone blends used for the pants can be adjusted softer or harder depending on the fabric condition and sensitive skin areas.

Zweigeteilter Beckenschaft | © Pohlig GmbH
Two-part pelvic socket

In developing the pelvic socket, we have set ourselves the goal of reducing the fixed portions of the shaft in order to achieve greater freedom of movement. We also wanted to optimize the control of the prosthesis. The two-part pelvic socket with silicone inlays meets these requirements.

Verschlusstechnik | © Pohlig GmbH
Closure technology

A special locking technique opens and closes the two-part socket. The silicone pants can be easily closed with a velcro fastener. The velcro fastener can be retightened even after the pelvic harness has been put on.

Hüftexprothese | © Pohlig GmbH
Hüftexprothese  | © Pohlig GmbH

Two-part pelvic socket with silicone hip pants

All of the benefits at a glance

With the implementation of our innovative socket concept, it was possible to optimize both socket functionality and comfort:

1. Improved control of the prosthesis:

  • Compressing HTV silicone pants allows better control of the prosthesis
  • There is a reduced longitudinal stroke of the prosthesis compared to conventional systems. This enables better length compensation.
  • A special measure and shape detection technique can achieve better prosthesis response.
  • Thanks to the comfortable socket system and newly developed joint, the pelvic rotation can be compensated and a symmetrical, steady gait pattern can be achieved.

2. Hygienic and skin-protecting stump bed

  • The extremely easy-care HTV silicone allows for simple cleaning. The material can be cleaned with soap and water and disinfected with alcohol.
  • Silicone is non-allergenic. Sweat residues, the most common cause of reactions, can be quickly washed out. Nothing stands in the way of immediate reuse, as no drying times occur during cleaning.
  • The silicone pants provide a good protective layer for the skin.
Reinigung der HTV-Silikonhose | © Pohlig GmbH
Konventioneller Beckenkorb | © Pohlig GmbH

And what are the alternatives?

Of course, we also provide conventional pelvic harnesses, although from a functional point of view there are no reasons to deprive new users of modern treatment technologies. Experienced users who do not wish to expend extra effort with closures – or who have high demands when it comes to cosmetic appearance and volume in the pelvic area – can alternatively choose a pelvic socket made of carbon with a semi-flexible proportion in the back area and individual silicone hip pants. After several years of experience, the use of a socket system in combination with silicone pants is the method of choice and brings a great advantage in the quality of care for hip prosthetics.
